The 111699 is a steel wall-mounted enclosure with a single door, designed for electrical and control gear applications. It measures 600 mm in height, 600 mm in width, and 250 mm in depth, providing ample space for various components. The enclosure features two hinges and two locks for secure access, and it is constructed to meet the IP66 protection standard, ensuring high resistance to dust and water ingress. It has a permissible mounting plate load capacity of up to 2500 N according to IEC 62208 standards. The mounting method includes 9 mm drilling dimensions for wall fastening on the back plate, allowing for intermediate mounting options. The enclosure complies with relevant safety and insulation standards, including resistance to normal heat conditions. The model code for this enclosure is CS-66/250, and it is part of the CS series, suitable for use in LV systems switch and control gear applications.
Die obige Beschreibung basiert auf unseren Büro-/Lagernotizen. Einige Daten können ungenau sein - beziehen Sie sich auf Ihre Teilenummer.

Wenn Sie sich nicht sicher sind, ob dieses Teil perfekt passt, kontaktieren Sie uns bitte.
