The 1037274 is an incremental rotary encoder with a 3000 quadrature count per revolution, offering user-selectable options. It features a solid shaft with various mounting configurations, including face mount flange, and supports multiple shaft types such as blind hollow and through hollow shafts. The encoder provides up to 65,536 pulses per revolution (16-bit resolution). It has a housing diameter of 60 mm and an enclosure rating of IP65/IP67 for protection against dust and water. The device includes a 6-channel communication interface with HTL / Push-pull output, an initialization time of approximately 40 ms, and an output frequency of up to 600 kHz. It operates within a supply voltage range of 10Vdc to 32Vdc (nominal 12Vdc/24Vdc), with a load current capacity of up to 30 mA and low power consumption.
Die obige Beschreibung basiert auf unseren Büro-/Lagernotizen. Einige Daten können ungenau sein - beziehen Sie sich auf Ihre Teilenummer.

Wenn Sie sich nicht sicher sind, ob dieses Teil perfekt passt, kontaktieren Sie uns bitte.
