The 1272 series includes various electrical components and accessories designed for high-capacity power applications. It features aluminum four-hole NEMA lugs rated for 1272 kcmil aluminum or copper conductors, with installation dies numbered 161, 727, 352, and 579, and measuring approximately 11-1/4 inches in length. The pad dimensions are 3 inches wide by 3-5/8 inches long and 1/2 inch thick. Additionally, the 1272 series encompasses PVC-coated pull boxes with a 24-inch 90-degree configuration, hub size of 1-1/2 inches, and a gray finish. Other components include aluminum compression lugs with a 90-degree bend for aluminum and copper terminations, rated for 1272 kcmil conductors, featuring a four-hole NEMA pad and a 1/2-inch bolt. The series also includes electrical equipment such as air over horsepower motors rated at 1775 RPM, 3-phase, 60Hz, with a 326T frame size. Mounting options include wall or ceiling configurations with LED lamp types, and copper busbars with dimensions of 20 mm x 1272 mm x 5 mm, rated for a maximum current of 320 A. Additionally, there are transformer potential parts and related accessories within the 1272 series designed for power distribution and control applications.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
