The 060L112666 is a temperature-controlled electric switch designed for regulating, monitoring, and alarm systems in industrial applications. It features a single-pole double-throw (SPDT) contact configuration and can directly control single-phase AC motors up to 2 kW. Equipped with a remote capillary sensor measuring 9.5 mm in diameter and 85 mm in length, it operates within a temperature range of 50°C to 100°C (122°F to 212°F). The thermostat has an automatic reset function and is suitable for ambient temperatures up to 65°C, with a maximum of 80°C for short durations. It is rated for 16A at 400VAC and is commonly used in temperature regulation and safety monitoring systems.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
