This 120-sized component features a working stroke ranging from 100 mm to 1100 mm with a size designation of 120. It includes a spindle diameter of 15 mm and offers a stroke reserve of 0 mm. The design incorporates a reversing backlash with a theoretical value of ≤150 µm. The technical specifications also include a timer, front panel valve, pneumatic valve, pushbutton actuator, and push-in L-fitting for versatile operation. Additionally, it has an effective drive pinion diameter of approximately 39.79 mm, a toothed-belt pitch of 5 mm, and optional mounting positions. The gear unit ratio is 1:1, capable of reaching a maximum rotational speed of 5000 rpm, and conforms to VDMA24364 zone III standards. The valve actuator size is 120, with a flange hole pattern F0507, a swivel angle of 90°, and an end-position adjustment range of 0° to 5°.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
