The 1320770 is a bellows gripper designed for precise gripping applications. It features a size of 22 mm with a stroke length of 12 mm and operates with a downward single-acting movement. The gripper is constructed from aluminum and is suitable for gripping objects with a minimum diameter of 24 mm and a maximum diameter of 31.5 mm. It is actuated in the downward direction, with the connection positioned in the direction of motion, and uses EPDM bellows material. The device is capable of operating at a frequency of 4 Hz and an operating pressure of 8 bar, with an M5 connection. Its installation position is arbitrary, making it versatile for various automation setups.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
