The 1470769 is an electric cylinder designed for precise linear motion applications. It features a size of 25 mm with a stroke length of 50 mm and a stroke reserve of 0 mm. The piston rod is threaded M8, and the reversing backlash is minimal at approximately 0.1 mm, ensuring accurate positioning. The drive utilizes a recirculating ball screw spindle powered by a fixed stepper motor, providing reliable and smooth operation. Constructed from wrought aluminum alloy with a smooth anodized finish, this cylinder offers durability and lightweight performance. It operates at a voltage rating of 24 VAC, with an amperage rating of 3 A, and supports a duty cycle of 100%, making it suitable for continuous operation in automation systems. The spindle has a diameter of 10 mm with a pitch of 10 mm per revolution, and the step angle at full step is 1.8 degrees with a tolerance of ±5%.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
