The 156680 is a compact, double-acting pneumatic cylinder with a 16 mm piston diameter and a 10 mm stroke. It features elastic cushioning rings at both ends for smooth operation and can be mounted in any position. The cylinder is designed for position detection with a magnet and includes a female threaded rod at the piston-rod end. It operates within a pressure range of 1.5 to 10 bar and offers space-efficient installation, requiring approximately 50% less space compared to standard ISO 15552 cylinders. The 156680 is suitable for applications demanding high force in both directions of travel and reliable retraction and extension of the piston.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
