The 1621524 is a shielded M23 circular cable connector from the SH series, featuring a straight long design with SPEEDCON fast locking mechanism. It has a total of 13 positions, including 8 power contacts, 4 signal contacts, and a protective earth (PE) contact. The connector utilizes socket contact connection types with crimping for secure attachment. It is suitable for cable mounting applications with a clamping range of 7.5mm to 18mm. The shell size corresponds to M23-13, accommodating various pin or socket contacts, and supports litz wire cross sections of at least 0.25 mm². The power contacts have a contact diameter of 2 mm and are rated for 8A at 50V AC/DC (signal contacts rated for 8A at 630V AC/DC). The design ensures reliable connections with quick locking and robust construction for demanding environments.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
