The 1688816 is a D-Sub male plug connector featuring nine pin contacts arranged in two rows within a shell size 1 housing. It is designed with pin-type contacts for secure electrical connections and supports crimp termination style for wire mounting. The connector is angled and fixed using a 3 mm hole, making it suitable for applications requiring a flat-ribbon cable connection. Made from sturdy copper alloy with gold-plated pins, it can operate at temperatures up to 125°C. The 1688816 includes a 3D CAD model for design integration.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
