The 101176503 is a safety interlock switch from the AZM 161 series, designed with a thermoplastic enclosure and double-insulation for enhanced safety. It features a body measuring 130 mm x 114 mm x 30 mm, equipped with 6 contacts that support electrical parameters of 24V DC / 2.5A and 250V AC / 4A. The switch includes an interlock mechanism with protection against incorrect locking, manual release, and screw connections with a clamping force of 2000N. It is rated IP67 for ingress protection and suitable for Ex-Zone 22 environments. Constructed for long-lasting performance, it offers a mechanical durability of up to 1,000,000 cycles.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
