This 100000000000 is an electrical protection and control device designed for versatile industrial applications. It features an operational voltage range from 230VAC 50/60Hz up to 690VAC 50/60Hz, with a rated operational current of 1000A at 35°C. The device is mounted using screws with the neutral position on the right. It includes a 1P + N earth leakage circuit breaker rated at 40A, C-characteristic, and 30mA sensitivity, capable of handling up to 10,000A. The 100000000000 incorporates a residual current device (RCD) for comprehensive circuit protection, and a contactor with a 440V DC coil, 2-pole configuration, and a rated capacity of 1000A. An isolating transformer supplies control circuits with AC input voltages between 230V and 400V. Additional components include a corrosion-resistant potentiometer, a DOL starter rated at 1000 VA for 415V AC single-phase operation, and a sturdy steel enclosure measuring 1000 x 1000 x 300mm with IP66 protection. The assembly is designed for robust industrial environments, providing reliable protection and control functionalities.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
