The 1036564 is an incremental rotary encoder with a 2048 quadrature pulses per revolution, designed for precise angular measurement. It features a through hollow shaft and operates within a supply voltage range of 10 to 32 V DC, typically 12 V or 24 V DC. The encoder offers a TTL / RS-422 communication interface with six signal channels, an initialization time of approximately 40 milliseconds, and an output frequency up to 600 kHz. It belongs to the DFS60 series and provides a duty cycle accuracy of ±0.05°. The device is suitable for applications requiring reliable position feedback and high-resolution rotational data.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
