The 1036724 is an incremental encoder designed for precise rotational measurement. It features a programmable configuration with six signal channels and a 32 ms initialization time. The encoder has a solid shaft with a diameter of 10 mm and is configured for face mounting with a flange. It operates within a supply voltage range of 4.5 V to 32 V DC and consumes approximately 0.7 W of power without load. The device provides an electronically gated reference signal at 90°, along with A and B signals for position encoding. Its output frequency can reach up to 600 kHz, and it supports a load current of up to 30 mA. The encoder includes a 5-meter flying lead for electrical connection.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
