The 1056336 is an incremental rotary encoder featuring a quadrature output with high resolution up to 16 bits. It offers compact installation depth and configurable settings, including output voltage, zero pulse position, zero pulse width, and the number of pulses. The encoder utilizes a male M23, 12-pin radial connector and operates within a supply voltage range of 4.5 to 5.5 V. It provides a single reference signal at a 90° electric position and has a weight of approximately 0.299 kg. Designed for precise motion detection, 1056336 is suitable for various industrial applications requiring reliable incremental encoding.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
