The 1056523 is an incremental encoder designed with a DFS60B-S4PB10000 type, featuring an axial flange and solid shaft mounting. It operates within a supply voltage range of 4.5Vdc to 32Vdc (including 6Vdc, 12Vdc, and 24Vdc options) and provides high-resolution measurement with a step angle of 0.01°, a measuring step of 90°, and pulses per revolution of 1000. The encoder offers precise measurement deviation at non-binary line counts, with an error limit of ±0.05°. It utilizes magnetic sensing principles and conforms to Type 4 (EN ISO 14119) for safety standards. The device is suitable for applications requiring accurate rotational position feedback in industrial environments.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
