The 1056662 is an incremental rotary encoder featuring a compact design with an installation depth suitable for various applications. It offers high resolution up to 16 bits and includes options for programmable parameters such as output voltage, zero pulse position, zero pulse width, and the number of pulses. The encoder has a male M23, 12-pin radial connector and operates within a supply voltage range of 10 to 32 V DC (nominal 12 V or 24 V). It provides a reference signal with a 90° electric position, and measures pulses per revolution up to 1,250, with electronically controlled measuring steps at 90°. The device is designed with a blind hollow shaft for versatile mounting.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
