The 1056677 is an incremental encoder designed for precise rotational position measurement. It features a solid shaft and a face mount flange, with a housing diameter of 60 mm. The encoder operates with a supply voltage range of 10 V to 32 V DC, typically 12 V or 24 V DC, and provides a signal output with 500 pulses per revolution in quadrature (incremental) mode, supporting up to six signal channels. It utilizes a photoelectric retro-reflective sensing principle with a dual lens system for reliable detection at minimal distances to the reflector. The connection is made via an M23, 12-pin axial connector. The encoder has a mean time to dangerous failure (MTTFd) of 300 years according to EN ISO 13849-1 standards.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
