The 1070750 is an incremental rotary encoder featuring 4,096 pulses per revolution. It has a compact design with a 6mm diameter shaft and a 5/8 inch size, suitable for precise position measurement. The encoder provides HTL and TTL output signals and includes an 8-wire universal cable connection, with a supply voltage range of 4.5 to 30 V. Its electric reference signal is positioned at 90°, enabling accurate quadrature detection for motion control applications.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
