The 1076248 is an incremental rotary encoder featuring a 100 quadrature signal, suitable for precise position measurement applications. It has a through hollow shaft with rear clamping for mechanical mounting and includes an 8-wire cable with a male M23, 12-pin connector, and a length of 0.5 meters. The device operates within a supply voltage range of 4.5 to 5.5 V and provides a single reference signal. Its compact dimensions are approximately 16.2 mm in width, 48.5 mm in height, and 31.8 mm in depth. Designed based on photoelectric proximity sensing principles with background suppression, it ensures accurate detection and measurement in various industrial settings.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
