The 1094512 is an incremental rotary encoder designed for precise position measurement. It features a universal 8-wire cable connection of 0.5 meters in length and operates within a supply voltage range of 4.5 V to 30 V. The encoder provides a reference signal with a single channel and a 90° electric phase shift. It has a solid shaft with a face mount flange, a resolution of 30 mm, and a scanning range of up to 30 meters. The protective field height is 1,200 mm, and it offers response times of 12 ms for uncoded signals and 20 ms for coded signals. This device is suitable for applications requiring reliable position feedback in various industrial environments.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
