The 1126690 is a rotary incremental motor feedback system designed for precise position detection. It features 4,096 lines per revolution and a measuring step of 90° divided by the number of lines, ensuring high-resolution measurement. The device includes commutation signals and connects via a stranded wire with a 15-pin radial connector. It operates within a voltage range of approximately 4.5 V to 5.5 V DC and consumes about 60 mA of current. This sensor provides accurate rotational feedback suitable for various automation and control applications.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
