The 170ADI35000 is a digital input module designed for use with the Modicon Momentum series. It features 32 discrete inputs operating at 24V DC, with an input voltage range of -3 to 30 V and guaranteed low-level voltage detection between -3 to 5 V. The module provides isolation between channels and ground at 500V AC, ensuring reliable operation in safety-critical applications. It includes 32 LEDs for channel status indication and has compact dimensions of 125mm (width) x 47.5mm (depth) x 141.5mm (height). Suitable for distributed control architectures, this module offers a current draw of approximately 2.5mA at signal level.
The above description is based on our office/warehouse notes. Some data may be inaccurate - refer to your part number.

If you're unsure whether this part is a perfect match, please contact us.
