The 11100198 - EIL580P STATOR 63MM is a high-performance optical incremental encoder designed for precise rotational measurement. It features a hollow shaft with a diameter of 14 mm and a size of 58 mm, equipped with a stator coupling suitable for mounting on a bolt circle of 63 mm with M3 mounting holes. The encoder provides programmable output signals (TTL or HTL) with resolutions up to 65,536 pulses per revolution, making it ideal for high-dynamic applications. It operates within a voltage supply range of 4.75 to 30 VDC and includes reverse polarity protection and short-circuit proofing. The device is designed for demanding environments, with an IP65-rated flange connector (M12) and a minimum operating temperature of -40°C. Its precise optical sensing and interpolated output ensure accurate position feedback in various industrial automation and motion control systems.
La descripción anterior se basa en nuestras notas de oficina/almacén. Algunos datos pueden ser inexactos - consulte su número de pieza.

Si no está seguro de si esta pieza es una combinación perfecta, póngase en contacto con nosotros.
