The 130B2446 is a sine wave filter designed for use with FC 100 and FC 300 series frequency controllers. It offers a degree of protection IP20 and supports nominal power ratings of 5.5 to 7.5 kW at voltages between 380-500V, and 3 to 3.7 kW at 200-240V. The filter can handle a continuous rated current of 17 A and a maximum output frequency of 120 Hz. Its dimensions are approximately 268 (or 322) mm in height, 130 mm in width, and 205 mm in depth, with a net weight of around 10.5 kg. The 130B2446 functions as an RFI filter, providing improved power quality for the connected drive systems.
La descrizione sopra riportata si basa sulle note del nostro ufficio/magazzino. Alcuni dati potrebbero essere imprecisi: fare riferimento al numero di parte.

Se non siete sicuri che questo pezzo sia perfettamente compatibile, contattateci.
