1144048-07
Image for illustration purposes only.
If you're unsure whether this part is a perfect match, please contact us.
New Sealed — New and unused, supplied in original manufacturer packaging.
New — New and unused. Original manufacturer packaging may be opened, missing or replaced.
Refurbished — Professionally inspected, tested and restored to full working condition.
Used — Previously used, inspected and tested as fully operational.
Condition: New
Priced on Request
Est. shipping: October 05 2026
Product Overview:
The 1144048-07 is an incremental scanning head equipped with a built-in encoder and magneto resistive scanning technology. It features a line count of 2048, a grating period of 395.0 µm, and a drum outside diameter of approximately 257.50 mm. The output signal is approximately 1V peak-to-peak, with a cutoff frequency of 300 Hz (-3 dB). Designed for precise measurement applications, it incorporates a magnetic grating reading head suitable for high-accuracy positioning and control systems.
Heidenhain specialises in precision measurement and control systems, offering products such as encoders, length gauges, and CNC controls. Known for their accuracy and reliability, Heidenhain\\\\\\\\\\\\\\\'s technologies are widely used in industries like machine tools, electronics, and automation.
