1169566-05
Image for illustration purposes only.
The 1169566-05 is an incremental rotary encoder with an integral bearing designed for mounting via stator coupling. It features a line count of 1024 and provides HTL output signals, suitable for high-frequency scanning up to 300 kHz. Part of the ERN 1300 series, this encoder offers high reliability and rugged construction, making it ideal for precise rotary measurement applications. It includes a tapered shaft with a diameter of 9.25 mm and a 1:10 gear ratio, and is equipped with a 12-pin plug connector for secure electrical connections.
Heidenhain specialises in precision measurement and control systems, offering products such as encoders, length gauges, and CNC controls. Known for their accuracy and reliability, Heidenhain\\\\\\\\\\\\\\\'s technologies are widely used in industries like machine tools, electronics, and automation.
